ARG22838

anti-CD163 antibody [EDHu-1]

anti-CD163 antibody [EDHu-1] for ELISA,Flow cytometry,ICC/IF,IHC-Frozen sections,IHC-Formalin-fixed paraffin-embedded sections,Western blot and Human,Bovine,Guinea pig,Pig,Rhesus Monkey,Sheep

M1/M2/TAM Marker antibody; Macrophage Marker antibody; M2 Macrophage Marker antibody
publication_link Publication1

Overview

Product Description Mouse Monoclonal antibody [EDHu-1] recognizes CD163
Mouse anti Human CD163 antibody, clone EDHu-1 recognizes the human CD163 cell surface antigen, a 130-140 kDa glycoprotein expressed by tissue macrophages. CD163 is not expressed by resting peripheral blood leucocytes but expression may be induced on monocytes by culture in dexamethasone.Clone EDHu-1 is reported to inhibit the binding of haptoglobin/hemoglobin to CD163 (Madsen et al. 2004).Truncation mutation analysis demonstrates binding of EDHu-1 occurs via the N-terminal region of CD163 containing the first three scavenger receptor, Cysteine-rich, SRCR domains the third domain being critical as, cleavage of this domain at the major cleavage site ASP-265 abrogates binding to the N-terminal fragment.
Tested Reactivity Hu, Bov, Gpig, Pig, R. Mk, Sheep
Tested Application ELISA, FACS, ICC/IF, IHC-Fr, IHC-P, WB
Host Mouse
Clonality Monoclonal
Clone EDHu-1
Isotype IgG1
Target Name CD163
Antigen Species Human
Immunogen Leucocytes harvested from the pleural cavity of patients with idiopathic spontaneous pneumothorax
Conjugation Un-conjugated
Alternate Names sCD163; M130; Scavenger receptor cysteine-rich type 1 protein M130; MM130; CD antigen CD163; Hemoglobin scavenger receptor

Application Instructions

Application Suggestion
Tested Application Dilution
ELISAAssay-dependent
FACSNeat
ICC/IFAssay-dependent
IHC-FrAssay-dependent
IHC-PAssay-dependent
WBAssay-dependent
Application Note FACS: Use 10 µl of the suggested working dilution to label 10^6 cells in 100 µl.
* The dilutions indicate recommended starting dilutions and the optimal dilutions or concentrations should be determined by the scientist.

Properties

Form Liquid
Purification Purification with Protein A.
Buffer PBS and 0.09% Sodium azide
Preservative 0.09% Sodium azide
Concentration 1 mg/ml
Storage Instruction For continuous use, store undiluted antibody at 2-8°C for up to a week. For long-term storage, aliquot and store at -20°C or below. Storage in frost free freezers is not recommended. Avoid repeated freeze/thaw cycles. Suggest spin the vial prior to opening. The antibody solution should be gently mixed before use.
Note For laboratory research only, not for drug, diagnostic or other use.

Bioinformation

Database Links

GeneID: 397031 Pig CD163

GeneID: 533844 Bovine CD163

GeneID: 9332 Human CD163

Gene Symbol CD163
Gene Full Name CD163 molecule
Background CD163 protein is a member of the scavenger receptor cysteine-rich (SRCR) superfamily, and is exclusively expressed in monocytes and macrophages. It functions as an acute phase-regulated receptor involved in the clearance and endocytosis of hemoglobin/haptoglobin complexes by macrophages, and may thereby protect tissues from free hemoglobin-mediated oxidative damage. This protein may also function as an innate immune sensor for bacteria and inducer of local inflammation. Alternatively spliced transcript variants encoding different isoforms have been described for this gene. [provided by RefSeq, Aug 2011]
Function CD163: Acute phase-regulated receptor involved in clearance and endocytosis of hemoglobin/haptoglobin complexes by macrophages and may thereby protect tissues from free hemoglobin-mediated oxidative damage. May play a role in the uptake and recycling of iron, via endocytosis of hemoglobin/haptoglobin and subsequent breakdown of heme. Binds hemoglobin/haptoglobin complexes in a calcium-dependent and pH-dependent manner. Exhibits a higher affinity for complexes of hemoglobin and multimeric haptoglobin of HP*1F phenotype than for complexes of hemoglobin and dimeric haptoglobin of HP*1S phenotype. Induces a cascade of intracellular signals that involves tyrosine kinase-dependent calcium mobilization, inositol triphosphate production and secretion of IL6 and CSF1. Isoform 3 exhibits the higher capacity for ligand endocytosis and the more pronounced surface expression when expressed in cells.

After shedding, the soluble form (sCD163) may play an anti-inflammatory role, and may be a valuable diagnostic parameter for monitoring macrophage activation in inflammatory conditions. [UniProt]
Highlight Related products:
CD163 antibodies; CD163 ELISA Kits; CD163 Duos / Panels; Anti-Mouse IgG secondary antibodies;
Related news:
New antibody panels and duos for Tumor immune microenvironment
Anti-SerpinB9 therapy, a new strategy for cancer therapy
RIP1 activation and pathogenesis of NASH
Research Area M1/M2/TAM Marker antibody; Macrophage Marker antibody; M2 Macrophage Marker antibody
Calculated MW 125 kDa
PTM A soluble form (sCD163) is produced by proteolytic shedding which can be induced by lipopolysaccharide, phorbol ester and Fc region of immunoglobulin gamma. This cleavage is dependent on protein kinase C and tyrosine kinases and can be blocked by protease inhibitors. The shedding is inhibited by the tissue inhibitor of metalloproteinase TIMP3, and thus probably induced by membrane-bound metalloproteinases ADAMs.
Phosphorylated.

Images (7) Click the Picture to Zoom In

  • ARG22838 anti-CD163 antibody [EDHu-1] IHC-P image

    Immunohistochemistry: sheep stained with ARG22838 anti-CD163 antibody [EDHu-1] at 1:150 dilution.

    From Aili Wang et al. Int J Artif Organs (2023), doi: 10.1177/03913988231208631, Fig. 6 (a).

  • ARG22838 anti-CD163 antibody [EDHu-1] IHC-Fr image

    Immunohistochemistry: Human tonsil cryosection stained with ARG22838 anti-CD163 antibody [EDHu-1]. (Low power).

  • ARG22838 anti-CD163 antibody [EDHu-1] IHC-Fr image

    Immunohistochemistry: Human tonsil cryosection stained with ARG22838 anti-CD163 antibody [EDHu-1]. (Medium power).

  • ARG22838 anti-CD163 antibody [EDHu-1] IHC-Fr image

    Immunohistochemistry: Human tonsil cryosection stained with ARG22838 anti-CD163 antibody [EDHu-1]. (High power).

  • ARG22838 anti-CD163 antibody [EDHu-1] IHC-Fr image

    Immunohistochemistry: Human tonsil cryosection stained with ARG22838 anti-CD163 antibody [EDHu-1], red in A and Mouse anti Human CD21 antibody, clone LB21, green in B. C is the merged image with nuclei counterstained blue using DAPI. (Low power).

  • ARG22838 anti-CD163 antibody [EDHu-1] IHC-Fr image

    Immunohistochemistry: Human tonsil cryosection stained with ARG22838 anti-CD163 antibody [EDHu-1], red in A and Mouse anti Human CD21 antibody, clone LB21, green in B. C is the merged image with nuclei counterstained blue using DAPI. (Medium power).

  • ARG22838 anti-CD163 antibody [EDHu-1] IHC-Fr image

    Immunohistochemistry: Human tonsil cryosection stained with ARG22838 anti-CD163 antibody [EDHu-1], red in A and Mouse anti Human CD21 antibody, clone LB21, green in B. C is the merged image with nuclei counterstained blue using DAPI. (High power).

Specific References

Optimal treatment of tannic acid for the anti-calcification of bovine jugular veins and the underlying mechanism

IHC-P / Sheep

Aili Wang et al.
Int J Artif Organs.,  (2023)
