ARG30327
Microvascular Density Antibody Panel
Angiogenesis antibody; MVD Antibody; Microvascular Density Antibody
Component
Cat No | Component Name | Host clonality | Reactivity | Application | Package |
---|---|---|---|---|---|
ARG66347 | anti-Ki-67 antibody [SQab1897] | Rabbit mAb | Hu | IHC-P | 20 μl |
ARG52748 | anti-CD31 antibody | Rabbit pAb | Hu, Ms, Rat, Pig | ICC/IF, IHC-FoFr , IHC-Fr, IHC-P, WB | 20 μl |
ARG66200 | anti-Desmin antibody [SQab1722] | Rabbit mAb | Hu, Ms, Rat | IHC-P, WB | 20 μl |
ARG66381 | anti-alpha smooth muscle Actin antibody [SQab18108] | Rabbit mAb | Hu, Ms, Rat, AGMK, Bov, Ctl, Dog, Pig, Zfsh | FACS, ICC/IF, IHC-Fr, IHC-P, WB | 20 μl |
ARG65351 | Goat anti-Rabbit IgG antibody (HRP) | Goat pAb | Rb | ELISA, IHC-P, WB | 50 μl |
Overview
Product Description | Microvascular Density Antibody (MVD) Panel is an all-in-one solution to make angiogenesis research easy and economic. This antibody panel comprises the proliferation marker Ki-67 antibody, endothelial marker CD31 antibody, and mural cell markers Desmin and alpha-SMA antibodies. All the antibodies in this panel have excellent IHC performance. It is the best solution to examine the process of angiogenesis in tumor tissues and xenograft model. Related news: Angiogenesis & MVD Antibody Panels are released |
---|---|
Target Name | Microvascular Density |
Alternate Names | Microvascular Density antibody; CD31 antibody; Desmin antibody; Ki-67 antibody; alpha smooth muscle Actin antibody |
Properties
Storage Instruction | For continuous use, store undiluted antibody at 2-8°C for up to a week. For long-term storage, aliquot and store at -20°C or below. Storage in frost free freezers is not recommended. Avoid repeated freeze/thaw cycles. Suggest spin the vial prior to opening. The antibody solution should be gently mixed before use. |
---|---|
Note | For laboratory research only, not for drug, diagnostic or other use. |
Bioinformation
Gene Full Name | Antibody Panel for Microvascular Density |
---|---|
Research Area | Angiogenesis antibody; MVD Antibody; Microvascular Density Antibody |
Images (22) Click the Picture to Zoom In
-
ARG52748 anti-CD31 antibody IHC-P image
Immunohistochemistry: Formalin-fixed and Paraffin-embedded MDA-MB-231 (tumor xenograft study) stained with ARG52748 anti-CD31 antibody.
Antigen Retrieval Buffer: Bond Epitope Retrieval Solution. -
ARG66200 anti-Desmin antibody [SQab1722] WB image
Western blot: 30 µg of MEF (negative control) and Mouse heart lysates stained with ARG66200 anti-Desmin antibody [SQab1722] at 1:5000 dilution.
-
ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] IHC-Fr image
Immunohistochemistry: Mouse liver and Mouse aorta stained with ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] at 1:100 dilution.
From Masahiro Terasawa et al. Cells (2023), doi: 10.3390/cells12222666, Fig. 2A.
-
ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] WB image
Western blot: 30 μg of NRK-49F cells treated with TGF beta 1 (10 ng/ml) for 0~48 hours. Cell lysates were stained with ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] at 1:2000 dilution, overnight at 4°C.
-
ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] ICC/IF image
Immunofluorescence: NRK-49F cells treated with TGF beta 1 (10 ng/ml) for 0~48 hours. Cells were fixed with 4% PFA for 15 min at room temperature and permeabilizated by 0.5% Triton X-100. Cells were stained with ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] at 1:200 dilution, overnight at 4°C.
-
ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] FACS image
Flow Cytometry: HeLa cells were fixed with 4% paraformaldehyde (10 min) and then permeabilized with 0.1% TritonX-100 for 15 min. The cells were then stained with ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] (red) at 1:100 dilution in 1x PBS/1% BSA for 30 min at 4°C, followed by Alexa Fluor® 488 labelled secondary antibody. Unlabelled sample (green) was used as a control.
-
ARG66200 anti-Desmin antibody [SQab1722] IHC-P image
Immunohistochemistry: Formalin‐fixed and paraffin‐embedded Human colon tissue stained with ARG66200 anti-Desmin antibody [SQab1722] at 1:8000 dilution.
Antigen retrieval: Heat mediated was performed using Tris/EDTA buffer pH 9.0
-
ARG66347 anti-Ki-67 antibody [SQab1897] IHC-P image
Immunohistochemistry: Formalin-fixed and paraffin-embedded Human tonsil tissue stained with ARG66347 anti-Ki-67 antibody [SQab1897]. Antigen Retrieval: Heat mediation was performed using Tris/EDTA buffer (pH 9.0).
-
ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] IHC-P image
Immunohistochemistry: Formalin-fixed and paraffin-embedded placenta stained with ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] at 1:2000 dilution. Antigen Retrieval: Heat mediated was performed using Tris/EDTA buffer (pH 9.0).
-
ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] WB image
Western blot: 10 µg of HeLa, HaCat, 293, LnCap, PC-3 and T47D cell lysates stained with ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] at 1:2000 dilution.
-
ARG52748 anti-CD31 antibody WB image
Western blot: 30 µg of HUVEC lysate stained with ARG52748 anti-CD31 antibody at 1:500 dilution.
-
ARG66200 anti-Desmin antibody [SQab1722] IHC-P image
Immunohistochemistry: Formalin‐fixed and paraffin‐embedded Human placenta tissue stained with ARG66200 anti-Desmin antibody [SQab1722] at 1:8000 dilution.
Antigen retrieval: Heat mediated was performed using Tris/EDTA buffer pH 9.0
-
ARG66347 anti-Ki-67 antibody [SQab1897] IHC-P image
Immunohistochemistry: Formalin-fixed and paraffin-embedded Human esophageal cancer tissue stained with ARG66347 anti-Ki-67 antibody [SQab1897]. Antigen Retrieval: Heat mediation was performed using Tris/EDTA buffer (pH 9.0).
-
ARG66347 anti-Ki-67 antibody [SQab1897] IHC-P image
Immunohistochemistry: Formalin-fixed and paraffin-embedded Human cervical cancer tissue stained with ARG66347 anti-Ki-67 antibody [SQab1897]. Antigen Retrieval: Heat mediation was performed using Tris/EDTA buffer (pH 9.0).
-
ARG66347 anti-Ki-67 antibody [SQab1897] IHC-P image
Immunohistochemistry: Formalin-fixed and paraffin-embedded Human diffuse large B-cell lymphoma stained with ARG66347 anti-Ki-67 antibody [SQab1897]. Antigen Retrieval: Heat mediation was performed using Tris/EDTA buffer (pH 9.0).
-
ARG66347 anti-Ki-67 antibody [SQab1897] IHC-P image
Immunohistochemistry: Formalin-fixed and paraffin-embedded Human esophageal cancer tissue stained with ARG66347 anti-Ki-67 antibody [SQab1897]. Antigen Retrieval: Heat mediation was performed using Tris/EDTA buffer (pH 9.0).
-
ARG66347 anti-Ki-67 antibody [SQab1897] IHC-P image
Immunohistochemistry: Formalin-fixed and paraffin-embedded Human tonsil tissue stained with ARG66347 anti-Ki-67 antibody [SQab1897]. Antigen Retrieval: Heat mediation was performed using Tris/EDTA buffer (pH 9.0).
-
ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] WB image
Western blot: 10 µg of MDCK, MDBK, Pig heart, Zebrafish and Cos-7 lysates stained with ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] at 1:2000 dilution.
-
ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] WB image
Western blot: 10 µg of Mouse brain, Rat kidney and Rat liver lysates stained with ARG66381 anti-alpha smooth muscle Actin antibody [SQab18108] at 1:2000 dilution.
-
ARG52748 anti-CD31 antibody IHC-P image
WB analysis of LLC xenograft mouse tumor tissue lysate stained with ARG52748 anti-CD31 antibody.
Reproduced under the Creative Commons license from Xu Fei et al. J Exp Clin Cancer Res., (2018) 37:207 Doi: 10.1186/s13046-018-0878-0, Fig. 7C.
-
ARG52748 anti-CD31 antibody WB image
WB analysis of LLC xenograft mouse tumor tissue lysate stained with ARG52748 anti-CD31 antibody.
Reproduced under the Creative Commons license from Xu Fei et al. J Exp Clin Cancer Res., (2018) 37:207 Doi: 10.1186/s13046-018-0878-0, Fig. 7C.
-
ARG52748 anti-CD31 antibody IHC image
Cryostat sections from Mouse Retinal stained with ARG52748 anti-CD31 antibody.
Reproduced under the Creative Commons license from Lin Chin-I et al. July/August 2019, 6(4) ENEURO.0391-18.2019 1–17, Doi: 10.1523/ENEURO.0391-18.2019, Fig. 4 A-C.
